Frequency Response

60 Hz – 25 kHz
Nominal Impedance

6 ohms
Sensitivity (1W@1M)

88.5 dB
Maximum SPL

107.4 dBA
Power Handling (RMS)

65 W
Recommended Amplifier Requirements

20 – 65 W
Drive Unit Complement

6 1/2" MMP II cone bass driver
1" C-CAM pivoting Gold Dome tweeter
Adjustment Controls

HF Level Switch (+3 dB / 0 dB / -3 dB)
Overall Diameter (Including Grille)

250 mm (913/16")
Overall Depth (Including Grille)

120 mm (43/4")
Mounting Depth

116 mm (49/16")
Cut-Out Hole Diameter

211 mm (81/4")
Optional Square Grille - Outer Dimensions

249 x 249 mm (9 3/16")
Fixing Type

3 position Tri-Grip dog fixings
Construction Material

Mineral filled ABS, RoHS compliant
Weight

1.92 kg (4 lb 4 oz)
Pre-Construction Bracket

CM-B
Back Box

CSM-BOX
Sold As

Single Unit

‍
