Frequency Response

50 Hz – 25 kHz
Nominal Impedance

6 ohms
Sensitivity (1W@1M)

90 dB
Maximum SPL

111.6 dBA
Power Handling (RMS)

120 W
Recommended Amplifier Requirements

30 – 120 W
Drive Unit Complement

8" MMP II cone bass driver
1" C-CAM pivoting Gold Dome tweeter
Adjustment Controls

HF Level Switch (+3 dB / 0 dB / -3 dB)
Overall Diameter (Including Grille)

285 mm (111/4")
Overall Depth (Including Grille)

126 mm (415/16")
Mounting Depth

122 mm (413/16")
Cut-Out Hole Diameter

247 mm (93/4")
Fixing Type

3 position Tri-Grip dog fixings
Optional Square Grille - Outer Dimensions

285 x 285 mm (111/4")
Construction Material

Mineral filled ABS, RoHS compliant
Weight

2.72 kg (6 lb)
Pre-Construction Bracket

CL-B
Back Box

CML-BOX
Sold As

Single Unit

‍
