System Format

3-way
Sensitivity (2.83v @ 1m, Free-Field)

86.5 dB
Sensitivity (2.83v @ 1m, Installed)

N/A
Recommended Amplifier Power (RMS into 4 Ohm, Music Signal)

130 – 500 W
Continuous Power Handling (CTA 426-B)

250 W
Nominal Impedance

4 Ohms
Minimum Impedance (20Hz to 20kHz)

3.9 Ohms @ 140 Hz
Drive Unit Complement

1 x 8” (203 mm) HDT C-CAM Bass Drivers
1 x 3” (76 mm) HDT C-CAM Mid-Range Driver
1 x MPD III Tweeter
Frequency Response Free-Field (-6dB)

49 Hz – 60 kHz
Frequency Response, In-Room (-6dB)

32 Hz – 60 kHz
Maximum Peak SPL (AES75, Z-weighted)

119 dB
Bass Alignment

HiVe II Ported
Port Tuning Frequency

38 Hz
Crossover Frequency

LF/MF: 700 Hz
MF/HF: 2.6 kHz
External Dimensions with all accessories fitted (H x W x D)

447.7 x 230 x 357.3 mm (1715/8 x 91/16 x 141/16”)
Weight (each)

14 kg (30 lb 14 oz)
Sold As

Pair

‍
