System Format

2-way
Sensitivity (2.83v @ 1m, Free-Field)

85 dB
Sensitivity (2.83v @ 1m, Installed)

N/A
Recommended Amplifier Power (RMS into 4 Ohm, Music Signal)

130 – 300 W
Continuous Power Handling (CTA 426-B)

150 W
Nominal Impedance

4 Ohms
Minimum Impedance (20Hz to 20kHz)

4.0 Ohms @ 225 Hz
Drive Unit Complement

1 x 6” (152 mm) HDT C-CAM Bass-Mid Drivers
1 x MPD III Tweeter
Frequency Response Free-Field (-6dB)

55 Hz – 60 kHz
Frequency Response, In-Room (-6dB)

44 Hz – 60 kHz
Maximum Peak SPL (AES75, Z-weighted)

114 dB
Bass Alignment

HiVe II Ported
Port Tuning Frequency

50 Hz
Crossover Frequency

LF/HF: 2.5 kHz
External Dimensions with all accessories fitted (H x W x D)

320 x 185 x 303 mm (125/8 x 75/16 x 1115/16”)
Weight (each)

8.5 kg (18 lb 12 oz)
Sold As

Pair

‍
