System Format

3-way
Sensitivity (2.83v @ 1m, Free-Field)

88.5 dB
Sensitivity (2.83v @ 1m, Installed)

N/A
Recommended Amplifier Power (RMS into 4 Ohm, Music Signal)

130 – 600 W
Continuous Power Handling (CTA 426-B)

300 W
Nominal Impedance

4 Ohms
Minimum Impedance (20Hz to 20kHz)

4 Ohms @ 150 Hz
Drive Unit Complement

2 x 8” (203 mm) HDT C-CAM Bass Drivers
1 x 3” (76 mm) HDT C-CAM Mid-Range Driver
1 x MPD III Tweeter
Frequency Response Free-Field (-6dB)

44 Hz – 60 kHz
Frequency Response, In-Room (-6dB)

25 Hz – 60 kHz
Maximum Peak SPL (AES75, Z-weighted)

122 dB
Bass Alignment

HiVe II Ported
Port Tuning Frequency

33 Hz
Crossover Frequency

LF/MF: 700 Hz
MF/HF: 2.6 kHz
External Dimensions with all accessories fitted (H x W x D)

1155 x 383 x 475 mm (451/2 x 151/16 x 1811/16”)
Weight (each)

26.5 kg (58 lb 7 oz)
Sold As

Pair

‍
