System Format

3-way
Sensitivity (2.83v @ 1m, Free-Field)

87.5 dB
Sensitivity (2.83v @ 1m, Installed)

N/A
Recommended Amplifier Power (RMS into 4 Ohm, Music Signal)

130 – 500 W
Continuous Power Handling (CTA 426-B)

250 W
Nominal Impedance

4 Ohms
Minimum Impedance (20Hz to 20kHz)

3.9 Ohms @ 165 Hz
Drive Unit Complement

2 x 6” (152 mm) HDT C-CAM Bass Drivers
1 x 3” (76 mm) HDT C-CAM Mid-Range Driver
1 x MPD III Tweeter
Frequency Response Free-Field (-6dB)

64 Hz – 60 kHz
Frequency Response, In-Room (-6dB)

54 Hz – 60 kHz
Maximum Peak SPL (AES75, Z-weighted)

121 dB
Bass Alignment

Sealed
Port Tuning Frequency

N/A
Crossover Frequency

LF/MF: 800 Hz
MF/HF: 2.7 kHz
External Dimensions with all accessories fitted (H x W x D)

205 x 537 x 335 mm (81/16 x 211/8 x 133/16”)
Weight (each)

15.3 kg (33 lb 12 oz)
Sold As

Single Unit

‍
