Technical Specifications
Amplifier Section

   Amplifier Design: Class AB
   Power Output (FTC): 250W/Ch, 8Ω
   Continuous Power Output: 230W/Ch, 8Ω
   Maximum Power Output: 390W/Ch, 4Ω
   Speaker Impedance: 4Ω minimum
   Damping Factor: 350 (1kHz, 8Ω)

Audio Performance

   Total Harmonic Distortion (THD): <0.03%
   Intermodulation Distortion: <0.03%
   Frequency Response: 10Hz–100kHz (+0dB, -0.4dB)
   Signal-to-Noise Ratio: >115dB (IHF "A" weighted)
   Crosstalk / Separation: >70dB

Analog Inputs

   Balanced Input: XLR
   Unbalanced Input: RCA
   Input Sensitivity / Impedance, Unbalanced: 2V / 12kΩ
   Input Sensitivity / Impedance, Balanced: 4V / 200kΩ

Gain

   Unbalanced Gain: 26.5dB
   Balanced Gain: 20.5dB

Speaker Outputs

   Speaker Terminals: Dual 5-way binding posts
   Speaker Connection: Single-wire and bi-wire compatible
   Minimum Speaker Impedance: 4Ω

Control & Connectivity

   12V Trigger: Input / Output
   USB Port: Software updates
   Service Port: Factory service use
   Remote Control: Included

Display

   Display Type: Front-panel TFT display
   Display Modes: VU Meter and Spectrum Display

General

   Power Requirements: 230V, 50Hz
   Power Consumption: 550W
   Standby Power Consumption: <0.5W
   BTU Rating: 1513 BTU/h (4Ω, 1/8th power)
   Dimensions (W × H × D): 431 × 148 × 405mm
   Front Panel Height: 131mm
   Net Weight: 17.5kg
   Finish: Black

‍
