Technical Specifications
Digital-to-Analog Conversion

   DAC: ESS ES9028PRO 8-Channel DAC
   DAC Architecture: Differential, optimized for stereo operation

Audio Performance

   Total Harmonic Distortion (THD): <0.0006%
   Frequency Response: 20Hz–20kHz (+0dB, -0.3dB)
   Channel Balance: ±0.5dB
   Dynamic Range: >99dB

Signal-to-Noise Ratio

   Unbalanced (RCA): >120dB
   Balanced (XLR): >125dB

Channel Separation

   Unbalanced (RCA): >105dB @ 10kHz
   Balanced (XLR): >110dB @ 10kHz

Analog Outputs

   Unbalanced Output (RCA): 1.96V
   Unbalanced Output Impedance (RCA): 100Ω
   Balanced Output (XLR): 4.2V
   Balanced Output Impedance (XLR): 2kΩ
   Balanced XLR Outputs: Fully balanced differential
   RCA Outputs: Single-ended

Digital Output

   Coaxial Digital Output: 1
   Function: CD transport output for connection to an external DAC

CD Playback

   Disc Type: Compact Disc
   Mechanism: High-precision floating CD mechanism
   Loading: Precision tray-loading mechanism

Display

   Display Type: Full-color TFT display
   Information: Album artwork and disc playback information

Control & Connectivity

   Network Connection: 1
   RS232: 1
   12V Trigger: 1
   External IR Remote Input: 1
   USB: 1
   Remote Control: Included

General

   Power Requirements: 230V, 50Hz
   Power Consumption: 25W
   Standby Power Consumption: <0.5W
   Dimensions (W × H × D): 431 × 148 × 385mm
   Front Panel Height: 131mm
   Net Weight: 8.8kg
   Finish: Black

‍
