Specification

TRANSDUCER

   Tweeter 1" Pinnacle Ring Radiator
   Mid-range/Mid-bass -
   Woofers Two 5 ¼” Turbine Cone
   Overall Frequency Response 35Hz - 50kHz
   Frequency Response (-3dB limits) 49Hz - 36kHz
   Recommended Amplifier Power 25 - 200W
   Amplifier Output Compatibility 8Ω / 6Ω / 4Ω
   Minimum Impedance (ohms) 3.9Ω
   Sensitivity (2.83V/1m) 87dB

CROSSOVER

   Tweeter/Mid-range Crossover Frequency 2500
   Mid-range/Mid-bass Crossover Frequency -

MEASUREMENTS

   Product Dims W x H x D (Includes width of feet) 255.4 x 1044.5 x 348.8mm
   10.1 x 41.1 x 13.7 in
   Product Weight (each) 39 lbs/17.7 kg
   Shipping Weight 49.6 lbs/22.5 kg

CABINETRY

   New CRC (Mid-Range Enclosure Type) -
   Mid-Bass / Woofer Enclosure Type Rear X-Port
   Available Finishes Black / Walnut / White
   Feet Spike and Pad
   Wall-Mountable (keyhole slots) No
   Binding Posts: Nickel-plated 5-Way Single

Certifications Non-Safety and Regulatory

   Hi-Res Certified Yes
   IMAX Certified Yes
   Shipping Dims (WxHxD) 456 x 350 x 1135mm
   (17.9x 13.8 x 44.7) in

‍
