System Format

3 - way
Frequency Response, In-Room (-6dB)

31 Hz - 35 kHz
Sensitivity (2.83v @ 1m)

87.5 dB
Nominal Impedance

8 Ohms
Minimum Impedance

4.0 Ohms @ 160 Hz
Maximum SPL (single, free-field)

110 dB
Power Handling (RMS)

200 W
Recommended Amplifier Requirements

80 - 200 W
Crossover Frequency

L.F: 750 Hz
M.F/ H.F: 2.8 kHz
Port Tuning Frequency

40 Hz
Bass Alignment

Bass reflex
Dual HiVe II port system
Drive Unit Complement

2 x 6" C-CAM RST II bass driver
1 x 3" C-CAM RST II mid-range driver
1 x 1" (25 mm) C-CAM Gold Dome tweeter with UD Waveguide II
External Dimensions (Including Grille and Terminals (H x W x D))

1000 x 185 x 332 mm (393/8 x 75/16 x 135/64")
External Dimensions (including Outrigger Feet and Spikes (H x W x D))

1045 x 274 x 389 mm (419/64 x 1025/32 x 155/16")
Weight (each)

19.3 kg (42 lb 9 oz)
Sold As

Pair

‍
