Technical Specifications
Amplifier Section
Power Output (FTC): 220W/Ch, 8Ω
Maximum Power Output (Non-FTC): 340W/Ch, 4Ω
Continuous Power Output (Non-FTC): 210W/Ch, 8Ω
Amplifier Design: Class AB
Total Harmonic Distortion (THD): <0.03%
Intermodulation Distortion: <0.03%
Damping Factor: 260 (20Hz–20kHz, 8Ω)
Channel Separation: >55dB
Frequency Response
Line Level Inputs: 10Hz–100kHz (+0dB, -0.5dB)
Digital Inputs: 10Hz–20kHz (+0dB, -0.4dB, Max)
Phono Input: 20Hz–20kHz (+0dB, -0.5dB)
Analog Inputs
Phono Input: Moving Magnet (MM)
Line Level Inputs (RCA): 3 pairs
Balanced Line Input (XLR): 1 pair
Digital Inputs
Coaxial Digital Inputs: 3
Optical Digital Inputs: 3
PC-USB: USB Audio Class 2.0
Bluetooth: aptX HD and AAC
HDMI ARC: 1
Digital Audio
Digital-to-Analog Converter: ESS ES9039Q2M DAC
Coaxial/Optical: SPDIF LPCM up to 24-bit/192kHz
PC-USB PCM: Up to 32-bit/384kHz
DSD: Up to DSD256 / 11.2MHz
DoP: Up to DSD128 / 5.6MHz
HDMI ARC: 2-channel PCM up to 24-bit/48kHz
Roon Tested: Yes
Analog Outputs
Speaker Outputs: Two sets, A/B user-selectable
Subwoofer Outputs: 2
Preamp Output: 1.92V / 100Ω
Line Output: 1
Balanced Output (XLR): 1 pair
Digital Output: 1
Signal-to-Noise Ratio
Phono Input: >80dB
Line Level Inputs (RCA): >105dB
Line Level Inputs (XLR): >100dB
Digital Inputs: >110dB
Input Sensitivity / Impedance
Phono Input (MM): 5.56mV / 47kΩ
Line Level Inputs (RCA): 356mV / 100kΩ
Line Level Inputs (XLR): 743mV / 50kΩ
Tone Controls
Bass: ±10dB at 100Hz
Treble: ±10dB at 10kHz
Control & Connectivity
Network Connection: 1
RS232: 1
12V Trigger: Input/Output
External IR Remote Input: 1
Rear USB: For software updates
Remote Control: Included
General
Power Requirements: 230V, 50Hz
Power Consumption: 520W
Standby Power Consumption: <0.5W
Network Wakeup: <2W
BTU Rating: 1476 BTU/h
Dimensions (W × H × D): 431 × 148 × 422mm
Front Panel Height: 132mm
Net Weight: 16.9kg
Finish: Black
