Specifications
HI-RES SUPPORT PCM 384kHz; DSD256
LINE OUTPUT VOLTAGE 2V; 3.4V max. (variable gain)
HP OUTPUT POWER RMS ≥5.57V/484mW @ 64Ω (4.4mm)
≥3.02V/286mW @ 32Ω (6.3mm)
HP OUTPUT IMPEDANCE <0.7Ω (3.5mm); <1.4Ω (4.4mm)
OUTPUT IMPEDANCE Line Section ≤50Ω
Headphone Section <1Ω
DYNAMIC RANGE 118dBA (both outputs)
SNR 118dBA (both outputs)
FREQUENCY RESPONSE 20Hz-90kHz (-3dB)
THD+N ≤0.0011% (6.3mm, 1.27V @ 16Ω);
≤0.0015% (4.4mm, 2.4V @ 32Ω);
POWER CONSUMPTION No signal ~0.55W; Max signal ~3.55W
DIMENSIONS 158 x 100 x 35mm
(6.2 x 3.9 x 1.4”)
NET WEIGHT 315g(0.69lbs)

‍
